1.85mm Vertical Launch PCB Jack Compression Mount, Stripline

1.85mm connectors were developed for use through 67 GHz. The interface uses a mostly air-dielectric with a support bead that is set back in the body of the connector to reduce bead interaction in a mated pair.

Features:
1. Frenquency range from DC to 67 GHz
2. .047 and .085 inch cables are applicable
3. Solderless PCB mount solutions are available

Applications:
1. High speed digital
2. Cable assemblies
3. Instrumentation
4. Test and measurement

1.85mm Vertical Launch PCB Jack Compression Mount, Stripline

Material and Plating
Body/Stainless Steel/Passivated
Supporting Bead/Ultem1000
Center Contact/Beryllium Copper/10u" Gold

Electrical
Impedance: 50 Ohm
Frequency Range: DC ~ 67 GHz
VSWR: 1.40 max.
Insulator Resistance: ≥ 5 GΩ
Center Contact Resistance: ≤ 4 mΩ
Outer Contact Resistance: ≤ 2.5 mΩ
Test Voltage: 500 V rms

Environmental
RoHS and REACH compliant

Certificate
ISO 9001 and IATF 16949

Ethical Sourcing
Conflict Minerals Reporting Template (CMRT)
